Catalogue Page
Product Info
Trade Drawing
• Hinge torque can be adjusted with screw
• Provide position control
• Suitable for left- and right-hand applications
• Fixed with M4 screw
MATERIAL
BODY: Delrin
SCREWS AND NUTS: Stainless Steel (AISI 304)
PERFORMANCE DETAILS
Axial load: (N)
Working load: 700
Breaking load weight: 1100
Radial load: (N)
Working load: 1400
Breaking load weight: 1800
Torque value: 0.8 N.m.
Working temperature: - 5ºC + 65ºC
Fasteners:
(Bolts and nuts are not supplied)
Screw and nut: M4
